Ability KeyValues

DataDriven Ability

A DataDriven ability is a collection KeyValues. KeyValues are simple, tree-based structures used for storing nested sections containing key/value pairs.

DataDriven abilities are defined inside scripts/npc/npc_abilities_custom.txt under a game addon folder.

This skeleton contains many keyvalues which will be expanded upon in this documentation.

"datadriven_skeleton"
{
    // General
    // ----------------------------------------------------------------------------------------
    "BaseClass"              "ability_datadriven"
    "AbilityBehavior"        "DOTA_ABILITY_BEHAVIOR_UNIT_TARGET"
    "AbilityTextureName"     "spellicon"
    "AbilityUnitTargetTeam"  "DOTA_UNIT_TARGET_TEAM_ENEMY"
    "AbilityUnitTargetType"  "DOTA_UNIT_TARGET_HERO | DOTA_UNIT_TARGET_BASIC"
    "AbilityUnitTargetFlags" "DOTA_UNIT_TARGET_FLAG_MAGIC_IMMUNE_ENEMIES"
    "AbilityUnitDamageType"  "DAMAGE_TYPE_MAGICAL"

    "AbilityType"            "DOTA_ABILITY_TYPE_BASIC"
    "MaxLevel"               "7"
    "RequiredLevel"          "-4"
    "LevelsBetweenUpgrades"  "7"

    "AbilityCastPoint"       "0.0"
    "AbilityCastAnimation"   "ACT_DOTA_ATTACK"
    "AnimationPlaybackRate"  "1"
    "AnimationIgnoresModelScale" "1"

    // Stats
    //----------------------------------------------------------------------------------------
    "AbilityDamage"           "0 0 0 0"
    "AbilityManaCost"         "0 0 0 0"
    "AbilityCooldown"         "0.0 0.0 0.0 0.0"
    "AbilityCastRange"        "0"
    "AbilityCastRangeBuffer"  "250"
    "AbilityChannelTime"      "0.0 0.0 0.0 0.0"
    "AbilityChannelledManaCostPerSecond" "30 35 40 45"
    "AbilityDuration"         "0.0 0.0 0.0 0.0"
    "AoERadius"               "250"

    // ...
}

BaseClass

BaseClass can be any default dota ability name or "ability_datadriven", which allows the use of the entire data driven ability system.

Using a dota ability as the BaseClass can be done either as an override of the ability (goes in npc_abilities_override.txt) or just as a new ability in npc_abilities.custom.txt which inherits the exposed variables. This however doesn't let us change/add its internal structure, as that code is locked in C++ code.

Here we'll focus on everything that concerns writing custom abilities from scratch, using the "BaseClass" "ability_datadriven".

AbilityBehavior

This describes how the ability works, the general behavior to perform when it is executed.

You can use different behaviors together, separated by spaces and | pipes.

Example:

"DOTA_ABILITY_BEHAVIOR_CHANNELLED | DOTA_ABILITY_BEHAVIOR_NO_TARGET"

List of every possible AbilityBehavior

AbilityBehavior	Description
DOTA_ABILITY_BEHAVIOR_NO_TARGET	Doesn't need a target to be cast. Ability fires off as soon as the button is pressed.
DOTA_ABILITY_BEHAVIOR_UNIT_TARGET	Needs a target to be cast on. Requires AbilityUnitTargetTeam and AbilityUnitTargetType, see Targeting.
DOTA_ABILITY_BEHAVIOR_POINT	Can be cast anywhere the mouse cursor is. If a unit is clicked, it will just be cast where the unit was standing.
DOTA_ABILITY_BEHAVIOR_PASSIVE	Cannot be cast.
DOTA_ABILITY_BEHAVIOR_CHANNELLED	Channeled ability. If the user moves, or is silenced/stunned, the ability is interrupted.
DOTA_ABILITY_BEHAVIOR_TOGGLE	Can be toggled On/Off.
DOTA_ABILITY_BEHAVIOR_AURA	Ability is an aura. Not really used other than to tag the ability as such.
DOTA_ABILITY_BEHAVIOR_AUTOCAST	Can be cast automatically. Usually doesn't work by itself in anything that is not an ATTACK ability.
DOTA_ABILITY_BEHAVIOR_HIDDEN	Can't be cast, and won't show up on the HUD.
DOTA_ABILITY_BEHAVIOR_AOE	Can draw a radius where the ability will have effect. Like POINT, but with an area of effect display. Makes use of AOERadius.
DOTA_ABILITY_BEHAVIOR_NOT_LEARNABLE	CAnnot be learned by clicking on the HUD. Example: Invoker's abilities.
DOTA_ABILITY_BEHAVIOR_ITEM	Ability is tied to an item. There is no need to use this, the game will internally assign this behavior to any "item_datadriven".
DOTA_ABILITY_BEHAVIOR_DIRECTIONAL	Has a direction from the hero. Examples: Mirana's Arrow, or Pudge's Hook.
DOTA_ABILITY_BEHAVIOR_IMMEDIATE	Can be used instantly, without going into the action queue.
DOTA_ABILITY_BEHAVIOR_NOASSIST	Ability has no reticle assist. (?)
DOTA_ABILITY_BEHAVIOR_ATTACK	Is an attack, and cannot hit attack-immune targets.
DOTA_ABILITY_BEHAVIOR_ROOT_DISABLES	Cannot be used when rooted.
DOTA_ABILITY_BEHAVIOR_UNRESTRICTED	Ability is allowed when commands are restricted. Example: Lifestealer's Consume.
DOTA_ABILITY_BEHAVIOR_DONT_ALERT_TARGET	Does not alert enemies when target-cast on them. Example: Spirit Breaker's Charge.
DOTA_ABILITY_BEHAVIOR_DONT_RESUME_MOVEMENT	Should not resume movement when it completes. Only applicable ot no-target, non-immediate abilities.
DOTA_ABILITY_BEHAVIOR_DONT_RESUME_ATTACK	Ability should not resume command-attacking the previous target when it completes. Only applicable to no-target, non-immediate abilities and unit-target abilities.
DOTA_ABILITY_BEHAVIOR_NORMAL_WHEN_STOLEN	Ability still uses its normal cast point when stolen. Examples: Meepo's Poof, Furion's Teleport.
DOTA_ABILITY_BEHAVIOR_IGNORE_BACKSWING	Ability ignores backswing pseudoqueue.
DOTA_ABILITY_BEHAVIOR_IGNORE_PSEUDO_QUEUE	Can be executed while stunned, casting, or force-attacking. Only applicable to toggled abilities. Example: Morphling's Attribute Shift.
DOTA_ABILITY_BEHAVIOR_RUNE_TARGET	Targets runes.
DOTA_ABILITY_BEHAVIOR_IGNORE_CHANNEL	Doesn't cancel abilities with _CHANNELED behavior.
DOTA_ABILITY_BEHAVIOR_OPTIONAL_UNIT_TARGET	Bottle and Wards.
DOTA_ABILITY_BEHAVIOR_OPTIONAL_NO_TARGET	(?)

Behavior Tooltips

The following behaviors will generate a line in the ability tooltip. You want at least one of 1 behavior of this list. The rest of the ability behaviors don't have any UI support yet.

The UI can only show one behavior tooltip, but internally it will behave as expected, as long two contradicting keys are not used together (like NO_TARGET with UNIT_TARGET).

AbilityBehavior	ABILITY: Tooltip	Takes precdence over:
DOTA_ABILITY_BEHAVIOR_NO_TARGET	No Target
DOTA_ABILITY_BEHAVIOR_UNIT_TARGET	Unit Target	POINT
DOTA_ABILITY_BEHAVIOR_POINT	Point Target
DOTA_ABILITY_BEHAVIOR_PASSIVE	Passive
DOTA_ABILITY_BEHAVIOR_CHANNELLED	Channeled	POINT and UNIT
DOTA_ABILITY_BEHAVIOR_TOGGLE	Toggle	POINT and UNIT
DOTA_ABILITY_BEHAVIOR_AURA	Aura	PASSIVE
DOTA_ABILITY_BEHAVIOR_AUTOCAST	Auto-Cast	UNIT_TARGET

For example, an ability with

"AbilityBehavior" "DOTA_ABILITY_BEHAVIOR_UNIT_TARGET | DOTA_ABILITY_BEHAVIOR_CHANNELED"

will be shown like this:

AbilityType

Omitting this will default to DOTA_ABILITY_TYPE_BASIC.

AbilityType	Description
DOTA_ABILITY_TYPE_BASIC	Normal ability, learnable at level 1 and upgradeable every 2 levels.
DOTA_ABILITY_TYPE_ULTIMATE	5 levels between upgrades, and requires level 6 to spend the first point on it. Also tags the ability as ultimate for the HUD.
DOTA_ABILITY_TYPE_ATTRIBUTES	Used for attribute_bonus.
DOTA_ABILITY_TYPE_HIDDEN	What for?

Additionally, ability level intervals and limits can be directly changed with these keyvalues inside the ability block:

MaxLevel

The UI currently supports the following ability level displays: 1, 3, 4, and 7.

You can still use any integer value as MaxLevel, and it will assign the proper level values internally, but it will use a combination of these UI display numbers, then "start again" to another UI.

Example:

"MaxLevel" "10"

RequiredLevel

At which level the ability can first be learned. This takes negative values, to enable for skills to be skilled at any point, because the next value sets the levels between ranks of the ability, including the first one.

LevelsBetweenUpgrades

How many levels to wait to be able to learnt he next rank.

Example:

"MaxLevel"              "7"
"RequiredLevel"         "-4"
"LevelsBetweenUpgrades" "7"

Results in an ability that can be first skilled at levels 3/10/17/24/31/38/45.

Max level of the heroes can be changed using the Lua SetCustomHeroMaxLevel(MAX_LEVEL) API function.

AbilityTextureName

The icon file name that should be used in the UI for this ability. You can reutilize the icon from another just by putting that ability name here if desired. The internal name of every default dota ability can be found in: Built-In Ability Names.

To use your own icons, place them in resources/flash3/images/spellicons in you game addon folder, and just directly refer to the image name without the path or the extension.

Format: 128x128 PNG

"AbilityTextureName" "warchasers_buff"

Reject Self-Cast

Added in Reborn:

"CastFilterRejectCaster" "1"

Cast While Hidden

Added in Reborn:

"IsCastableWhileHidden" "1"

Targeting

3 key elements set the rules for target selection: Team, Type, and Flags.

Team

AbilityUnitTargetTeam	Description
DOTA_UNIT_TARGET_TEAM_BOTH	All
DOTA_UNIT_TARGET_TEAM_ENEMY	Enemy
DOTA_UNIT_TARGET_TEAM_FRIENDLY	Allied
DOTA_UNIT_TARGET_TEAM_NONE	Default value by omission.
DOTA_UNIT_TARGET_TEAM_CUSTOM	(?)

Type

AbilityUnitTargetType	Targets
DOTA_UNIT_TARGET_ALL	Everything, including hidden entities.
DOTA_UNIT_TARGET_HERO	npc_dota_hero Heroes. DOTA_NPC_UNIT_RELATIONSHIP_TYPE_HERO
DOTA_UNIT_TARGET_BASIC	Basic units, including summons.
DOTA_UNIT_TARGET_MECHANICAL	npc_dota_creep_siege DOTA_NPC_UNIT_RELATIONSHIP_TYPE_SIEGE
DOTA_UNIT_TARGET_BUILDING	npc_dota_tower, npc_dota_building DOTA_NPC_UNIT_RELATIONSHIP_TYPE_BUILDING
DOTA_UNIT_TARGET_TREE	ent_dota_tree Examples: Tangos, Quelling Blade.
DOTA_UNIT_TARGET_CREEP	npc_dota_creature, npc_dota_creep Same as BASIC, but might not include things like some summons. Examples: Death Pact, Devour.
DOTA_UNIT_TARGET_COURIER	npc_dota_courier, npc_dota_flying_courier DOTA_NPC_UNIT_RELATIONSHIP_TYPE_COURIER
DOTA_UNIT_TARGET_NONE	Nothing!
DOTA_UNIT_TARGET_OTHER	Everything not included in the previous types.
DOTA_UNIT_TARGET_CUSTOM	Not exposed? Examples: Replicate, Sunder, Demonic Conversion, Tether, Infest...

Flags

Flags allow targeting units that are ignored by default (for example, magic immune enemies,) or to ignore specific types of units that will otherwise be targetable (like Ancients, or magic immune allies.)

AbilityUnitTargetFlags	Targets / Ignores
DOTA_UNIT_TARGET_FLAG_NONE	Default value by omission.
DOTA_UNIT_TARGET_FLAG_DEAD	Dead units, which are otherwise ignored.
DOTA_UNIT_TARGET_FLAG_MELEE_ONLY	Units with AttackCapabilities DOTA_UNIT_CAP_MELEE_ATTACK.
DOTA_UNIT_TARGET_FLAG_RANGED_ONLY	Units with AttackCapabilities DOTA_UNIT_CAP_RANGED_ATTACK.
DOTA_UNIT_TARGET_FLAG_MANA_ONLY	Units with mana, without "StatusMana" "0" in the npc_units file.
DOTA_UNIT_TARGET_FLAG_CHECK_DISABLE_HELP	Units with Disable Help on. Not sure how to make a DataDriven ability use it?
DOTA_UNIT_TARGET_FLAG_NO_INVIS	Ignores invisible units (with MODIFIER_STATE_INVISIBLE.)
DOTA_UNIT_TARGET_FLAG_MAGIC_IMMUNE_ENEMIES	Targets ENEMY units with MODIFIER_STATE_MAGIC_IMMUNE. Examples: Ensnare, Culling Blade, Primal Roar...
DOTA_UNIT_TARGET_FLAG_NOT_MAGIC_IMMUNE_ALLIES	Ignores FRIENDLY units with MODIFIER_STATE_MAGIC_IMMUNE. Example: Bane's Nightmare.
DOTA_UNIT_TARGET_FLAG_NOT_ATTACK_IMMUNE	Ignores units with MODIFIER_STATE_ATTACK_IMMUNE.
DOTA_UNIT_TARGET_FLAG_FOW_VISIBLE	Breaks when the unit goes into the fog of war. Examples: Mana Drain, Life Drain.
DOTA_UNIT_TARGET_FLAG_INVULNERABLE	Units with MODIFIER_STATE_INVULNERABLE. Examples: Assassinate, Recall, Boulder Smash...
DOTA_UNIT_TARGET_FLAG_NOT_ANCIENTS	Ignores units with "IsAncient" "1" defined. Example: Hand of Midas.
DOTA_UNIT_TARGET_FLAG_NOT_CREEP_HERO	Ignores units with "ConsideredHero" "1" defined. Examples: Astral Imprisonment, Disruption, Sunder.
DOTA_UNIT_TARGET_FLAG_NOT_DOMINATED	Ignores units with MODIFIER_STATE_DOMINATED.
DOTA_UNIT_TARGET_FLAG_NOT_ILLUSIONS	Ignores untis with MODIFIER_PROPERTY_IS_ILLUSION.
DOTA_UNIT_TARGET_FLAG_NOT_NIGHTMARED	Ignores units with MODIFIER_STATE_NIGHTMARED.
DOTA_UNIT_TARGET_FLAG_NOT_SUMMONED	Ignores units created through the SpawnUnit action.
DOTA_UNIT_TARGET_FLAG_OUT_OF_WORLD	Units with MODIFIER_STATE_OUT_OF_GAME.
DOTA_UNIT_TARGET_FLAG_PLAYER_CONTROLLED	Units controllable by a player, accesible with Lua's IsControllableByAnyPlayer().
DOTA_UNIT_TARGET_FLAG_PREFER_ENEMIES	Prioritizes units over trees when both are selectable.

Clean list:

• DOTA_UNIT_TARGET_FLAG_NONE
• DOTA_UNIT_TARGET_FLAG_DEAD
• DOTA_UNIT_TARGET_FLAG_MELEE_ONLY
• DOTA_UNIT_TARGET_FLAG_RANGED_ONLY
• DOTA_UNIT_TARGET_FLAG_MANA_ONLY
• DOTA_UNIT_TARGET_FLAG_CHECK_DISABLE_HELP
• DOTA_UNIT_TARGET_FLAG_NO_INVIS
• DOTA_UNIT_TARGET_FLAG_MAGIC_IMMUNE_ENEMIES
• DOTA_UNIT_TARGET_FLAG_NOT_MAGIC_IMMUNE_ALLIES
• DOTA_UNIT_TARGET_FLAG_NOT_ATTACK_IMMUNE
• DOTA_UNIT_TARGET_FLAG_FOW_VISIBLE
• DOTA_UNIT_TARGET_FLAG_INVULNERABLE
• DOTA_UNIT_TARGET_FLAG_NOT_ANCIENTS
• DOTA_UNIT_TARGET_FLAG_NOT_CREEP_HERO
• DOTA_UNIT_TARGET_FLAG_NOT_DOMINATED
• DOTA_UNIT_TARGET_FLAG_NOT_ILLUSIONS
• DOTA_UNIT_TARGET_FLAG_NOT_NIGHTMARED
• DOTA_UNIT_TARGET_FLAG_NOT_SUMMONED
• DOTA_UNIT_TARGET_FLAG_OUT_OF_WORLD
• DOTA_UNIT_TARGET_FLAG_PLAYER_CONTROLLED
• DOTA_UNIT_TARGET_FLAG_PREFER_ENEMIES

Fun with Flags

Flags were seen as AbilityUnitTargetFlags completions, but this is not their sole application.

The same applies to Team and Types.

• "Flags" and "ExcludeFlags" in a "Target" block gives control over how to target units to apply actions on them later:

"Target"
{
    "Center"    "CASTER"
    "Flags"     "DOTA_UNIT_TARGET_FLAG_DEAD"
}

• "TargetFlags" in a "LinearProjectile" action allows a LinearProjectile to ignore units that would otherwise be included by default in the Team+Type values, for example those with MODIFIER_STATE_INVISIBLE.
• "Aura_Flags" in a modifier with the other "Aura" keys can be used, for example, to make an aura modifier only affect ranged units by adding DOTA_UNIT_TARGET_FLAG_RANGED_ONLY.

The same applies for Teams and Types.

Example: Targets all friendly units in a radius of the caster, including couriers, buildings, and siege units. Excludes heroes, summons, and other player controlled units.

"Target"
{
    "Center"        "CASTER"
    "Radius"        "%radius"

    // AbilityUnitTargetTeam values.
    "Teams"         "DOTA_UNIT_TARGET_TEAM_FRIENDLY"

    // AbilityUnitTargetTypes
    "Types"         "DOTA_UNIT_TARGET_ALL"
    "ExcludeTypes"  "DOTA_UNIT_TARGET_HERO"

    // AbilityUnitTargetFlags
    "Flags"         "DOTA_UNIT_TARGET_FLAG_NOT_SUMMONED"
    "ExcludeFlags"  "DOTA_UNIT_TARGET_FLAG_PLAYER_CONTROLLED"
}

Example: Mirana's Arrow projectile rewrite that only hits heroes, including those that are magic immune:

"LinearProjectile"
{
    "Target"            "POINT"
    "EffectName"        "particles/units/heroes/hero_mirana/mirana_spell_arrow.vpcf"
    "MoveSpeed"         "857"
    "StartRadius"       "115"
    "EndRadius"         "115"
    "StartPosition"     "attach_attack1"
    "FixedDistance"     "3000"
    "TargetTeams"       "DOTA_UNIT_TARGET_TEAM_ENEMY"
    "TargetTypes"       "DOTA_UNIT_TARGET_HERO"
    "TargetFlags"       "DOTA_UNIT_TARGET_FLAG_MAGIC_IMMUNE_ENEMIES"
    "HasFrontalCone"    "0"
    "ProvidesVision"    "1"
    "VisionRadius"      "650"
}

With DOTA_UNIT_TARGET_FLAG_MAGIC_IMMUNE_ENEMIES, and with DOTA_UNIT_TARGET_FLAG_NONE:

Other keyvalues of the Action Target block

Line

To target units in a line between the caster and the targeted point.

Instead of the "Radius" keyvalue, which only takes one parameter, Line takes Length and Thickness integer values in a block like this:

"Line"
{
    "Length"    "600"
    "Thickness" "250"
}

Limiting the amount of targets

MaxTargets takes an integer value to limit the amount of targets the Target block will select.

"MaxTargets"    "10"

Random also takes an integer to be as "take up to this number of units randomly."

"Random"    "1"

(For more complex targeting, Lua scripting is the answer.)

ScriptSelectPoints

Its use is very rare, normally when the targeting is complex we would just use RunScript lua and do all the acitons inside the script.

ScriptSelectPoints
{
    ScriptFile
    Function
    Radius
    Count
}

A more in-depth explanation is needed to explain the complete usage of the Target block, as understanding the scope of the "Target" "TARGET" keyvalue is one of the most difficult things of the datadriven system.

Sources

• Constants wiki
• Abilities Data Driven wiki
• Extracted npc_abilities.txt file
• holdout_example keyvalues
• random github datamining
• brute-forcing everything for countless hours!

---

If you have any content to expand or improve this documentation, please let me know.

---
